VADTel-WM-15
DN 15 mechanical water meter platform with optional telemetry module for residential and light commercial AMR/AMI.
The VADTel-WM-15 is a DN 15 mechanical water meter with a roller register and an optional battery-powered telemetry module for remote reading. It is designed for potable-water metering in residential and light commercial installations that need reliable local measurement and scalable AMR/AMI integration. The telemetry module is an additional functionality without metrological impact: it picks up the register through a pulse interface and transmits readings and events over a cellular network.
Key features
- Mechanical DN 15 meter with a roller register reading directly in m³
- Add-on telemetry module (VAD-UM-01) for remote reading over GSM/GPRS
- Pulse reading interface with a fixed K-factor for telemetry pickup
- Hot- and cold-water variants, with or without telemetry
- Battery-powered telemetry electronics, independent of the metrology
- IP68 meter face and IP65 telemetry cover for outdoor and pit installation
Product identification
| Parameter | Value |
|---|---|
| Commercial name | VAD DN 15 Water Meter with Telemetry |
| Model family | VADTel-WM-15 (meter) / VAD-UM-01 (telemetry module) |
| Meter type | Mechanical water meter with roller register and add-on telemetry |
| Connection | DN 15 |
| Application | Residential and light commercial AMR/AMI |
| Origin | Made in EU |
Metrology
| Parameter | Value |
|---|---|
| Metering principle | Mechanical, roller register |
| Nominal flow (Qn) | 1.5 m³/h |
| Temperature class | T50 |
| Pulse constant (K-factor) | 4.440 × 10⁻⁶ m³/imp |
| Register unit | m³ (fine indication × 0.0001) |
Environmental and mechanical
| Parameter | Value |
|---|---|
| Water temperature range | +5 to +90 °C |
| Maximum admissible pressure | 16 bar (MAP 16) |
| Ingress protection | IP68 (meter face) / IP65 (telemetry cover) |
| Connection size | DN 15 |
Power supply
| Parameter | Value |
|---|---|
| Battery type | CR2450 lithium cell |
| Nominal voltage | 3 V |
Telemetry and communication
| Parameter | Value |
|---|---|
| Communication | GSM/GPRS |
| Reading source | Pulse interface, K = 4.440 × 10⁻⁶ m³/imp |
| Metrological impact | None — additional functionality over the metrology |
Configurations
| Variant | Water | Telemetry |
|---|---|---|
| Cold-water meter | Cold | — |
| Hot-water meter | Hot | — |
| Cold-water meter with telemetry | Cold | GSM/GPRS |
| Hot-water meter with telemetry | Hot | GSM/GPRS |
All variants share the DN 15 connection.
Regulatory framework
The VADTel-WM-15 belongs to the MID water-meter category and is designed in line with the following EU framework:
- MID 2014/32/EU (MI-001) — measuring instruments directive for water meters
- EN ISO 4064 series — metrological and technical requirements for water meters
- RED 2014/53/EU — radio equipment directive, applicable to telemetry-equipped variants
- CE marking — applies in line with the applicable conformity-assessment route
- RoHS / REACH — where supported by supplier declarations
Manufacturer
| Parameter | Value |
|---|---|
| Manufacturer | V.A.D. s.r.o. |
| Address | Konventná 6, 81103 Bratislava, Slovakia |
| Website | www.vadsro.eu |
| Support | inbox@vadsro.eu | +421-910-411-379 |
| Country of manufacture | Made in EU |
